“The new LYNX LC06 with 160x120px resolution is stirring up the market. The LC06 impresses with strong technical parameters at an unbeatable price.
Entering thermal imaging has never been so cost-effective. The shape of the camera is reminiscent of the well-known FLIR Scout TK, but is technically significantly more advanced and offers an unprecedented price-performance ratio.
The camera has a highly sensitive sensor with 160 x 120 resolution and offers a great picture at an extremely fair price. The camera enables the use of thermal imaging cameras on the first 0-150m.
It is clear that the HIKMICRO LYNX LC06 with 160Px cannot be compared with a device with 384x288px resolution, but offers a clear picture and great functionality up to 150m” – Review: Night Hunter. (https://www.nighthunter.eu/product/hikmicro-lynx-lc06/)
- High sensitivity thermal module with 160 x 120 resolution
- NETD < 35 mK (@25 ° C F#=1.1)
- Leading thermal image processing technology: Adaptive AGC, DDE, 3D DNR
- 720 × 540 resolution 0.2-inch LCOS display
- Built-in rechargeable lithium battery
- Up to 10 hours continuous operation
- Wi-Fi hot spot
- Type-C Interface
Specifications
Thermal Module
- Image Sensor: VOx uncooled focal plane arrays
- Resolution: 160 × 120
- Frame Frequency: 50 Hz
- Detection Range: 250m
- Pixel Interval: 17 μm
- Response Waveband: 8 μm to 14 μm
- NETD: ≤ 35 mK (@25°C),F#=1.1
- Focal Length: 6.2 mm
- IFOV: 2.74 mrad
- Field of View: 24.7° × 18.7° (H × V)
- Aperture: F1.1
Image Display
- Monitor 5.08 mm, LCOS, 720 × 540
- Palettes: Black hot, white hot, red hot, fusion
- FFC (Flat Field Correction) Mode: Auto, manual, external correction
- Digital Zoom: 1 ×, 2 ×, 4 ×
Smart Function
- Hot Track: Yes
- Detection Range: 219 m
System
- Storage: Built-in memory module (8 GB)
- Record Video: Yes
- Capture Snapshot: Yes
- Wi-Fi: Yes
- Standby Mode: Yes
Power Supply
- Battery Type: Rechargeable lithium battery
- Battery Operating Time:
- 10 hours continuous running with CVBS and Wi-Fi hot spot off (@25°C)
- 5 hours continuous running with CVBS and Wi-Fi hot spot on (@25°C)
- Battery Capacity Display: Yes
General
- Power: 5 VDC/2 A, 1.5 W, Type-C Interface
- Work Temperature/Humidity: From -20 °C to 55 °C (-4 °F to 131 °F); Humidity: 90% or less
- Protection Level: IP67
- Dimension: 158.3 mm × 61 mm × 57 mm
- Weight: 250 g
What's in the box
- HIKMICRO Lynx LC06 Handheld Thermal Monocular Camera
- Quick Start Guide
- Non-dust Cloth
- USB Cable
- Protective Bag
- Wrist Strap
