The Acebeam Ace 4 battery charger charges and monitors up to four cells at the same time. Each slot works on its own, so the charger can show a separate reading for every battery. The LCD screen displays cell voltage, charge current, charge time and battery type.
First, insert each battery with the correct polarity. Next, check the LCD screen to confirm the cell type and charging data. Built-in protection covers short circuits, overcurrent, overcharging and reversed polarity. Therefore, the charger adds useful safeguards for routine battery care.
Acebeam Ace 4 battery charger features
- Four battery slots with separate monitoring
- LCD screen for live charging data
- Cell voltage, current, time and battery type display
- Output: 4.2V / 3.65V / 1.5V
- Charge current: 500mA x 4 or 1000mA x 4
- Size: 145 x 104 x 39.5mm
- Weight: 260g
- Protection against short circuit, overcurrent, overcharge and reversed polarity
Power input and safe use
The charger accepts 100–240V AC at 50/60Hz, up to 600mA. It also accepts 12–24V DC at up to 2000mA. In addition, it is listed as meeting TUV GS, FCC, CE, C-TICK, CB and RoHS standards.
Use the Acebeam Ace 4 battery charger in a dry, well-aired place. Also inspect cells before charging and do not use damaged batteries. Keep the unit away from water, heat and flammable items. Finally, remove charged cells and unplug the charger when it is not in use. Images are for display only; please confirm the current product and price before purchase.
