Introducing the Pixfra Draco D225-4K Multispectral Binocular. The Pixfra PFI-D225-4K Draco Multispectral Binocular is a highly versatile and advanced imaging device designed to deliver comprehensive real-time insights across various operational scenarios. Weighing approximately 600 grams, its ergonomic, lightweight design ensures effortless portability and one-handed operation, making it suitable for extended use in the field. Its compact foldable structure, with dimensions of 97.9x178.4x36.7mm when folded and 121.1x282.1x54mm when unfolded, allows users to carry it comfortably while providing a robust array of features that meet diverse needs from thermal imaging to high-resolution digital night vision.
At the heart of the Draco binocular is its multi-functionality, integrating thermal imaging, 4K digital night vision, laser range finder, and infrared illumination into a single, all-in-one device. The thermal imaging component leverages a vanadium oxide uncooled focal plane detector with a spectral range of 8 to 14 micrometers, providing detailed thermal readings with a sensitivity of less than 18 mK at f/1.0. With a detection range of up to 1,300 meters, a 25mm focal length, and an F0.9 aperture, it delivers sharp thermal images with a 256x192 pixel resolution and a 50Hz frame rate. The thermal display supports six distinct color palettes, including White Hot, Black Hot, Iron Red, among others, allowing users to customise their view based on operational needs.
Complementing the thermal capabilities, the device features a 4K digital camera with a 1/1.8" CMOS sensor, offering a maximum resolution of 3840x2160 pixels and a frame rate of 50Hz. Its 55mm focal length and F2.0 aperture enable detailed visual imagery, with a field of view of 8.0 horizontally and 4.5 vertically. The digital night vision, powered by pixel-rich OLED technology, provides clear, high-contrast images in low-light conditions, outperforming competitors in clarity and detail. The devices dual imaging modes-thermal, visible, and picture-in-picture-allow seamless switching between thermal and digital views or combining both for comprehensive situational awareness.
Designed to operate effectively in harsh environments, the Draco binocular boasts an IP67 protection grade, ensuring resistance to water, dust, and extreme conditions. It features a replaceable 18650 lithium battery that supports over 9 hours of continuous operation at 25C with Wi-Fi turned off, making it suitable for prolonged field use. The device also includes Wi-Fi hotspot capabilities, GPS, compass, and a built-in 64GB storage for capturing and storing images, videos, and data logs. Its infrared illuminator operates at 850 nm with a range of 400 meters, supporting night vision and infrared illumination for complete darkness scenarios. Overall, the Pixfra PFI-D225-4K Draco Multispectral Binocular is a comprehensive, rugged, and technologically advanced tool, ideal for military, security, search and rescue, and scientific applications where detailed multispectral imaging is critical.
Features
- 6 thermal and 5 digital colour pallets
- 1920 x 1080, 0.49 inch, OLED
- Up to 9h at 25 c (wi-fi off) battery life
- Built-in 64gb storage
- 4-in-1 functionality
- Pips 3.0 technology
- Auto day & night mode
- Ergonomic grip, lightweight design
- Multi-function wheel and four-button layout
- Foldable eyecups with comfortable design
- Immersive 0.49-inch FHD OLED display with 18x ocular lens
- Ideal Application for Entry-level professional use, portability, shorter-range applications
Specifications
| Brand | Pixfra |
| Product Model | PFI-D225-4K |
| Thermal | |
| Detector Type | Vanadium oxide uncooled focal plane detector |
| Effective Pixels | 256 (H) x 192 (V) |
| Frame Rate | 50 Hz |
| Pixel Pitch | 12 um |
| Spectral Range | 8 um-14 um |
| Sensitivity (Netd) | -/<18 mK at f/1.0 |
| Focal Length | 25 mm |
| Aperture | F0.9 |
| Field Of View | H: 7.0, V: 5.3/H: 12.2 m, V: 9.3 m (at 100 m) |
| Focus Control Manual | |
| Close Focus Distance | 3 m (9.84 ft) |
| Detection Distance | 1,300 m (4,5265.09 ft) |
| Base Magnification | 4.3x |
| Digital Zoom | 1x-8x |
| Digital | |
| Detector Type | 1/1.8'' Progressive Scan CMOS |
| Max. Resolution | 3840 (H) x 2160 (V) |
| Frame Rate | 50 Hz |
| Focal Length | 55 mm |
| Aperture | F2.0 |
| Field Of View | H: 8.0, V: 4.5/H: 14.0 m, V: 8.8 m (at 100 m) |
| Focus Control Manual | |
| Close Focus Distance | 7 m (22.97 ft) |
| Base Magnification | 5.5x |
| Digital Zoom | 1x-8x |
| Display | |
| Screen Size | 1920 x 1080, 0.49 inch, OLED |
| Color Palettes Thermal | White Hot, Black Hot, Iron Red, Alarm, Green Hot, Sepia |
| Digital | Colour, Black White, Green, Yellow, Auto |
| Diopter | -5 D to 5 D |
| Eye Relief | 15 mm |
| Interpupillary Adjustment | 60 mm-74 mm |
| Function | |
| Image Modes | Thermal/Visible/Pip |
| Video Recorder | Yes |
| Snapshot | Yes |
| Wi-Fi Hotspot | Yes |
| Hot Spot Track | Yes |
| Ffc (Flat Field Correction) Mode | Auto Semi-Auto Manual |
| Standby Mode | Yes |
| Dpc (Defective Pixel Correction) | Yes |
| Mic | Yes |
| Compass | Yes |
| Pip | Yes |
| Gps | Yes |
| Local Album | Yes |
| Storage | Built-in 64 GB |
| Pips 3.0 | Yes |
| Smart Ir | Yes |
| Ir Illuminator Wavelength | 850 nm |
| Ir Illuminator Range | 400 m (1,312.34 ft) |
| Replaceable Ir Illuminator | Yes |
| Laser Range | 1,000 m (3,280.84 ft) |
| Laser Accuracy | -/+1 m (3.28 ft) |
| Laser Safety | Class 1 |
| Power | |
| Battery Type Replaceable | 18650 Lithium battery |
| Battery Operating Time | >/-9 h at 25 C (Wi-Fi off) |
| Power Supply | 5 VDC |
| Usb | USB Type-C |
| General | |
| Operating Temperature | -30 C to +55 C (-22 F to +131 F) |
| Operating Humidity | -/<95% |
| Protection Grade | IP67 |
| Packaging Dimensions | 286.0 mm x 228.0mm x 107.0 mm (11.26" x 8.98" x 4.21") (L x W x H) |
| Product Dimensions | 195.0 mm x 130.6 mm x 61.7 mm (7.68" x 5.14" x 2.43") (L x W) |
| Net Weight | -/<0.61 kg (1.34 lb) |
| Gross Weight | -/<2.5 kg (5.51 lb) |
| Ideal Application | Entry-level professional use, portability, shorter-range applications |
