Complementing the views produced by the Trinovid HD are construction details that make this optic able to stand up to the rigors of a life lived on the trail. First is a lightweight, sturdy, and corrosion-resistant magnesium alloy chassis that makes this binocular light and easy to handle. The body is covered with a textured rubber armor that protects it from bumps and impacts while giving it a slip-resistant grip in cold or wet conditions. Its optical tubes are nitrogen-filled and O-ring sealed to make it waterproof and submersible as well as fogproof when moving between extreme temperature fluctuations. To make handling the Trinovid easier are tethered objective lens covers that flip down and out of the way for observing, plus an ocular rainguard that attaches to the strap. Leica also includes their Adventure Strap system, which is a unique harness system that can be configured multiple ways for easier carrying and handling, while also doubling as a soft carrying bag to protect the binocular when not in use.
The Trinovid 20 BCA is available with a magnification factor of 8x.
Features
- 10x magnification
- 42mm objective lenses
- Compact roof prism optical path
- P40 phase corrected prism coatings increases contrast and provides true color rendition
- HLS (HighLux System): Highly reflective coatings on prisms reduce internal light loss
- HDC anti-reflection fully multi-coatings increase light transmission throughout optical path
- 340' field of view at 1000 yards
- Wide 61° apparent angle of view
- Short 5.2' close focus distance
- Closed bridge configuration
- 4-position click-stop twist-up rubber eyecups
- Tripod mountable with optional adapter
- ±4 right-eye dioptric correction
- Long 15mm eye relief
- 4.2mm exit pupil
- Lightweight and durable magnesium alloy housing
- Black, protective, textured rubber armoring for a slip-resistant grip
- Nitrogen-filled, water and fogproof. Submersible to 13' (4m)
- Tethered objective lens caps
- Weight: 25.75 oz
- Water and dirt repellent neoprene
- Strap/Harness system also acts as carrying bag
- Can be set up in two different bino-harness configurations or as a conventional strap
- Harness system relieves neck strain and transfers weight to shoulders
Specifications
| Delivery scope | contoured neoprene carrying strap, eyepiece caps, adventure strap |
| Magnification | 10 x |
| Front lens diameter | 42 mm |
| Exit pupil | 4.2 mm |
| Eye Relieve | 15 mm |
| Twilight factor | 20.5 |
| Light transmission | 90% |
| Field of view at 1,000 m | 113 m |
| Field of view at 1,000 yds | 355 ft |
| Subjective angle of view | 61° |
| Close focusing distance | approx. 5.3 ft /1.6 m |
| Diopter compensation | ± 4 diopters |
| Eyepieces for eyeglass wearers | yes, removable, with 4 click stops |
| Adjustable interpupillary distance | 58 – 76 mm |
| Focusing | Internal focusing via central focusing device |
| Watertightness | Watertight to a depth of 3 ft / 4 m |
| Housing | Magnesium, nitrogen-filled |
| Dimensions (W x H x D) | 140 x 117 x 65 mm |
| Weight | approx. 25.75 oz / 730 g |
