Introducing the first <20mK Thermal Scope with optical zoom.
With an extremely high thermal sensitivity (NETD<20mK) detector combining a powerful thermal camera of up to 640×512 @12µm @FO.9/F1.1, Thunder Zoom 2.0 ensures vivid, informative, and layered Images even under the slightest temperature differences.
The super large aperture guarantees improved temperature radiation capturing capability with incredible detail. You can easily distinguish your target from the background with different lens combos.
Thunder Zoom 2.0 offers dual FOV via optical zoom technology. Switching 35 mm camera to 60 mm camera, magnifications change from 1.8x to 3.1x and although the image is zoomed in it still maintains high quality.
Zero position is adjusted automatically when switching between two lenses, which means, you can zero one time for two lenses simultaneously. Please note: You should zero under the small FOV lens (50 mm lens in TH50Z 2.0 or 60 mm lens in TQ60Z 2.0).
Magnesium alloy design stands extreme environment from -30°C to 55°C, improved stability meets the long-lasting use.
The HIKMICRO battery pack offers up to 6.5 hours of use, and being replaceable and rechargeable, ensures uninterrupted operation even in low-temperature environments.
High shock resistance even on larger calibre’s to .375 H&H, 12-gauge and 9.3 × 64
Software enhancements include a new UI with a quick access menu, brightness and tone adjustments, multiple reticle and zeroing profiles, recoil-activated video and audio recording, and an automatic calibration countdown, offering a user-friendly and personalized experience.
Built-in WI-FI hotspot capability allows for real-time transfer of files, livestreaming to your smartphone and wireless firmware updates via the HIKMICRO SIGHT App after being connected to your phone via hotspot. Search HIKMICRO SIGHT on App Store (iOS System) or Google Play™ (Android System) to download it, or scan the QR code to download and install.
Key Features
- 640 × 512 resolution with 12 μm detector
- High sensitivity thermal module NETD < 20 mK (25°C, F# = 1.0)
- Dual FOV of 35 mm (F0.9) & 60 mm (F1.1) objective lenses
- 1024 × 768 resolution 0.39-inch OLED display
- Up to 6.5 hours of continuous operation
- Replaceable and rechargeable Li-ion battery packs
- High shock resistance up to 1,000 g/0.4 ms
- Detection range up to 3,000 m
Technical Specifications
Thermal Module
- Image Sensor: Uncooled Focal Plane Arrays
- Resolution: 640 x 512
- Frame Rate: 50 Hz
- Pixel Interval: 12 μm
- NETD: Less than 20 mK (25°C, F# = 1.0)
- Lens (Focal Length): 35 mm, F0.9 and 60 mm, F1.1
- Focus mode: Optical Zoom, Focus Ring
- Detection Range: 1,800 m / 3,000 m
- Focusing Distance: 35 mm: 7 m/ 60 mm: 9 m
- Magnification: 1.8x to 14.6x/3.1x to 25.0x (8x)
- Field of View (H × V), Degrees/m @100 m: 12.5° × 10°/21.9 m × 17.6 m; 7.3° × 5.9°/12.8 m × 10.2 m
Image display
- Display: 1024 × 768, 0.39-inch, OLED
- Palettes: Black Hot, White Hot, Red Hot, Fusion
- FFC (Flat Field Correction) Mode: Auto, Manual, External Correction
- Exit Pupil: 6 mm
- Eye Relief: 45 mm
- Diopter (Range): -5 D to 5 D
- Brightness Adjustment: Yes
- Tone Adjustment: Cold, Warm
System
- Record Video: On-board Video Recording
- Capture Snapshot: Yes
- Standby Mode: Yes
- Storage: Built-in EMMC (16 GB)
- PIP: Yes
- DPC: Yes
- Hotspot: Yes
- Hot Track: Yes
- Distance Measurement: Yes
- Audio Recording: Yes
- Recoil-activation Recording: Yes
- Recoil: 1,000 g/0.4 ms
- Zeroing profiles: 5
Power Supply
- Battery Type: Replaceable and Rechargeable Li-ion Battery
- Battery Operating Time: ≥ 6.5 h (25°C, with hotspot off)
- Type-C Power Supply: 5 V DC, 2 A; Supports External Power Supply
General
- Protection Level: IP67
- Dimension: 254.4 mm × 68.5 mm × 80.6 mm
- Weight: 843 g without battery
- Working Temperature: -30°C to +55°C (-22°F to 131°F)
What's in the box?
- HIKMICRO Thunder Zoom TQ60Z 2.0 60 mm Thermal Imaging Scope
- Bag
- Battery Charger
- Type-C Cable
- Battery x2
- Lint-free Cloth
- Quick Strat Guide
