Sensor:640x480,12μm,20mK; With 3 Scene modes and 6 Image modes; Compact design; Lens size 35mm ;18650 Rechargeable/Replaceable battery. Up to 1400m detection range, 1920x1080 OLED display, 50Hz, 1000m Rangefinder
| Model | Landsat 480 C | Landsat 640 C | |
| Classification | Multi-spectral Scope | ||
| Thermal Sensor | |||
| Type | Uncooled Vox(vanadium oxide) | ||
| Resolution(pixel) | 480*360 | 640*512 | |
| Pixel Size(µm) | 12*12 | 12*12 | |
| NETD | ≤20mK（0.02℃） | ≤20mK（0.02℃） | |
| Frame Rate(Hz) | 50 | 50 | |
| Human Detection Distance(m) | 1800 | 2100 | |
| Image Engine | PARD IREA | PARD IREA | |
| Objective lens(mm) | 35 | 45 | |
| Optical Magnification(x) | 2.5 | 2 | |
| Digital Zoom(x) | 2/4/6/8 | 2/4/6/8 | |
| Field of View (HxV) | Horizontal | 7.1° | 8.8° |
| Vertical | 7.1° | 8.8° | |
| Diagonal | 10.0° | 12.4° | |
| Focus range | 3m-∞ | 3m-∞ | |
| Visible Light Sensor | |||
| Resolution(pixel) | 2560*1440 | 2560*1440 | |
| Pixel Size(μm) | 2.9 | 2.9 | |
| Sensitivity(lux) | 0.001 | 0.001 | |
| Frame Rate(Hz) | Color mode: 60 / Mono: 30 | Color mode: 60 / Mono: 30 | |
| Image Engine | PARD VLEA | PARD VLEA | |
| Objective Lens(mm) | 50/70 | 50/70 | |
| Optical Magnification(x) | 4.4/6.1 | 4.4/6.1 | |
| Digital Zoom(x) | 2 | 2 | |
| Field of View (HxV) | Horizontal | 4.8°/3.4° | 4.8°/3.4° |
| Vertical | 4.8°/3.4° | 4.8°/3.4° | |
| Diagonal | 6.8°/4.8° | 6.8°/4.8° | |
| Focus range | 3m-∞ | 3m-∞ | |
| Display | |||
| Type | IPS | ||
| Resolution(pixel) | 800*800 | ||
| Reticle Style | 6 | ||
| Reticle Color | 4(Red/White/Yellow/Green) | ||
| Scene Mode | City/Rain/Forest | ||
| Image Mode | WT-HOT/BK-HOT/EDGE/RD-HOT/IN-HOT/SKY | ||
| Eye Relief(mm) | 100 | ||
| Diopter Adjustment(D) | -5~+3 | ||
| Photo / Video | |||
| Photo Resolution(pixel) | 1536*1536 | ||
| Photo Format | .JPG | ||
| Video Resolution(pixel) | Thermal: 768*768/Night Vision: 1440*1080 | ||
| Video Format | .mp4 | ||
| Storage(GB) | Micro SD card (Max. 128) | ||
| Main Function | |||
| LRF Detection Range(yd/m) | 1200/1000 | ||
| Ballistic Calculator | Yes | ||
| PIP | Yes | ||
| Gyroscope | Yes | ||
| Loop Recording | Yes | ||
| Recoil-activated recording | Yes | ||
| E-compass | Yes | ||
| Shutter | Mechanical shutter | ||
| Microphone | Yes | ||
| Firmware Upgrade | Yes | ||
| IR Illuminator | |||
| IR power(W) | 5 | ||
| IR Illuminating Level | 3 Levels | ||
| IR Distance(m) | 350 | ||
| IR Wavelength(nm) | 850/940 | ||
| Interfaces | |||
| USB Type-C | Yes | ||
| HDMI Output | Yes | ||
| Connections | |||
| WiFi | Yes | ||
| Supported Apps | PardVision2 | ||
| Power Supply | |||
| Battery type | Li-ion 21700*1 | ||
| Output Voltage(V) | 3.7 | ||
| Operating Time(h) | ≤6 | ||
| External Power Supply Type | Type-C | ||
| Environmental characteristic | |||
| Degree of Protection | IP67 | ||
| Operating Temp(°C/°F) | -20 ~ +50 / -4 ~ +122 | ||
| Recoil Resistance(J) | 6000 | ||
| Material | |||
| Housing | Aluminum Alloy | ||
| Objective lens | All-glass multi-coated lens | ||
| Measurement | |||
| Product Dimension(L * W * H, mm) | 265*92*90 | ||
| N.W/pcs(with IR illuminator&LRF&battery, g) | 750 | 785 | |
