The outstanding field of view offered by the Z6i 1-6x24 gives you the edge over others and especially helps in target acquisition. For instance, in narrow forest pathways, you can identify your target quickly and accurately. The 6x magnification means that you are also perfectly equipped for medium distances.
The illuminated Z6i 1-6x24 L stands out thanks to its 127.5 ft / 42.5 m field of view with a 1x magnification, which provides a larger overview when hunting. The 6x zoom provides the finest detail.
Technical Data
Magnification: 1-6x
Effective objective lens diameter (mm): 9.6-24
Exit pupil diameter (mm): 9.6-4.0
Exit pupil distance (mm) (Eye relief): 95
Field of view (ft/100 yds / m/100 m): 127.5-20.4 / 42.5-6.8
Field of view (degrees): 23.8-3.9
Field of view, apparent (degrees): 23.4
Dioptric compensation (dpt): -3 to +2
Light transmission (%): 90
Twilight factor acc. to ISO 14132-1: 2.8-12
Impact point corr. per click (in/100 yds / mm/100 m): 0.54 / 15
Max. elevation / windage adjustment range (in/100 yds / m/100 m): 72 / 2
Objective filter thread: M 27x0.75
Length (in / mm): 11.65 / 296
Weight (oz / g): 15.5 / 440
Central tube diameter (in / mm): 1.18 / 30
Functional temperature: -4 °F to +131 °F (-20 °C / +55 °C)
Storage temperature: -22 °F to +158 °F (-30 °C / +70 °C)
Submersion tightness: 13 ft / 4 m water depth (inert gas filling)
Illumination unit Brightness levels: Twilight: 0 - 32 / Day: 33 - 64
Operating time (h): Twilight factor at medium brightness: 1,400; daylight factor at medium brightness: 180
DOWNLOADS
INSTRUCTION MANUALS
Instruction manual - Z6: Download
TECHNICAL DATA
Technical Data - Z6: Download
WARRANTY
In addition to ergonomic design and innovative technology, our products are also distinguished by unmatched quality. We check every production step and every individual product for 100% quality prior to delivery. We therefore grant our customers an extensive warranty.
Our repair and service department will be happy to help you at all times if you have any further questions about the warranty on Swarovski Optik products.
