FIRST GENERATION NIGHT VISION BINOCULAR WITH ONE SCREEN
Enjoy an exceptional ergonomic design paired with a large screen, offering a superior and comfort viewing experience.
1920* 1080 HIGH-SENSITIVITY CMOS SENSOR
The 1080P CMOS sensor, with more pixels and a larger array, enhances image precision for effective target acquisition, elevating target searching to new heights
FULL COVERAGE EYE MASK BLOCKS ALL LIGHT
Enjoy a truly immersive experience with a soft, full-coverage silicone eye mask that effectively blocks out light, ensuring complete isolation for optima viewing comfort.
ADJUSTABLE INTERPUPILLARY DISTANCE
Merlin offers adjustable interpupillary distance to cater to tthe needs of different individuals.
Rotating the ring on the back ensures easy adjustment.
LARGE BUTTON EASY TO TOUCH AND OPERATE
The large button design ensures easy operation, even in low-light conditions or while wearing gloves, allowing quick and accurate pressing.
LONGER RUNNING TIME WITHE 21700 LHON BATTERY
Enjoy extended usage with the 21700 Li-ion battery, providing longer running time and reducing the need for frequent recharges. Ideal for prolonged activities and reliable performance.
COMPACT DESIGN
Featuring a compact and lightweight design, it can be worn comfortably around the neck for extended periods without causing fatigue. Additionally, its portability makes it easy to
pack into a backpack
Specifications
Sensor
Type: CMOS
Resolution(pixel): 1920*1080
Pixel Size(um): 2.9
Sensitivity(lux): 0.001
Frame Rate(Hz): 60(Color)/30(B&W)
Image Engine: PARD VLEA
Optics
Objective Lens(mm): 35/50
Optical Magnification(x): 3.2/4.6
Digital Zoom(x): 2
Field of View (Horizontal): 6.8°/4.8°
Field of View (Vertical): 5.1°/3.6°
Field of View (Diagonal): 8.5°/6.0°
Focus Range: 3m-∞
Diopter adjustment(D): -5~3
IR Illuminator
IR Type: VCSEL
IR Powe(W): 5
IR Illuminating Level: 3 Levels
IR Distance(m): 350
IR Wavelength(nm): 850/940
Display
Type: LED
Resolution(pixel): 640*480
Color Mode: Color/Black&White
Main Function
PIP: Yes
Auto Recording: Yes
Loop Recording: Yes
Time Stamp: Yes
Record Audio: Yes
Exposure Compensation: Yes
Storage(GB): Micro SD card (Max. 128GB)
Connections
USB Type-C: Yes
WiFi: Yes
Supported Apps: PardVision2
Power Supply
Battery Type: Lithium Ion 21700*1
Output Voltage(V): 3.7
Operating time(h,max): 6
External Power Supply(V): Type-C
Environmental Characteristic
Degree of Protection: IP67
Operating Temp(℃/℉): -30 ~ +55 / -22 ~ +131
Material
Housing: AL6061 & Composite
Objective Lens: Glass
Measurement
Product Dimension(L x W x H, mm): 220*137*58
N.W/pcs(with/without battery, g): 441.6
